2024 PKU HPCGame WP
发表更新笔记41 分钟读完 (大约6159个字)

2024 PKU HPCGame WP

今年参加了第一届PKU HPCGame，这是一场由北京大学计算中心等组织举办的个人超算竞赛。

题解情况如下：AC题目 A,B,C,D,F,I,L ; E,G,H 拿到部分分数；J,K,M,N 无解。这篇WriteUp主要是对我解决的题目的记录，以及一些解题思路的总结。

A. 欢迎参赛！

签到

B. 流量席卷土豆

小 X 为了让你学习超算知识，要求你必须使用 4 个计算节点，每个节点 4 个 tshark 进程同时从 16 个 PCAP 文件中提取 SSH 流量。为此，他要求你使用集群上的 Slurm 调度器运行这一步骤，同时把进行这一计算的 Slurm JobID 和最终使用 quantum-cracker 获得的密码同时交付给他。他会检查这一 JobID 对应的 Slurm Job 是否使用了 4 个计算节点，每个节点 4 个进程。否则他不会动用他的量子纠缠能力。

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
#!/bin/bash

PCAP_DIR=/lustre/shared_data/potato_kingdom_univ_trad_cluster/pcaps
OUT_DIR=$HOME

for i in $(seq 0 15); do
    srun -N4 --ntasks-per-node=4 tshark -r $PCAP_DIR/$i.pcap -Y ssh -w $OUT_DIR/$i.ssh.pcap
done

wait

mergecap -w $OUT_DIR/merged.pcap $OUT_DIR/*.ssh.pcap

/usr/bin/quantum-cracker $OUT_DIR/merged.pcap > $OUT_DIR/cracked_password.txt

echo "Slurm JobID: $SLURM_JOB_ID" >> $OUT_DIR/result.txt
echo "Cracked Password: $(cat $OUT_DIR/cracked_password.txt)" >> $OUT_DIR/result.txt

此题只需要满足两个要求：

  1. 写slurm脚本在一个进程中调用4个节点，每个节点上4个核，一共十六个进程提流量
  2. 使用给出的quantum-cracker破解流量中的ssh密码

判定较为宽松，不是严格要求必须分配进程，所以只需要调用到足够的核就能满足第一个条件。

C. 简单的编译

在本题中，你需要写一个简单的Makefile文件，和一个简单的CMakeLists.txt文件，来编译 Handout 中所提供的三个简单程序。

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
CC=g++
NVCC=nvcc
MPICC=mpic++
CFLAGS=-fopenmp

all: hello_cuda hello_mpi hello_omp

hello_cuda: hello_cuda.cu
	$(NVCC) -o hello_cuda hello_cuda.cu

hello_mpi: hello_mpi.cpp
	$(MPICC) -o hello_mpi hello_mpi.cpp

hello_omp: hello_omp.cpp
	$(CC) $(CFLAGS) -o hello_omp hello_omp.cpp

clean:
	rm -f hello_cuda hello_mpi hello_omp
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
#CMakeLists.txt
cmake_minimum_required(VERSION 3.10)
project(HelloWorld)

set(CMAKE_CXX_STANDARD 14)
set(CMAKE_CXX_FLAGS "${CMAKE_CXX_FLAGS} -fopenmp")

find_package(MPI REQUIRED)
find_package(CUDA REQUIRED)

enable_language(CUDA)

add_executable(hello_cuda hello_cuda.cu)
add_executable(hello_mpi hello_mpi.cpp)
add_executable(hello_omp hello_omp.cpp)

target_link_libraries(hello_mpi MPI::MPI_CXX)
target_link_libraries(hello_cuda ${CUDA_LIBRARIES})

makefile和cmakefile编写，套模板即可。

D. 小北问答CLASSIC

非常棒的知识问答，爱来自Neur0_5ama。

neuro


参赛昵称为Neur0_5ama,尝试作为Neuro单推人混入其中

最有意思的选项：

在高性能计算集群中，哪个工具通常用于作业调度和资源管理？ – Slurm 微信群 蜂群（确信）

E. 齐心协力

对于一百个(200, 40000)的矩阵 x ，计算如下结果，其中 A 、B 、C 和 D 都是 (40000, 40000) 的矩阵。其中四个矩阵需要被放置在四个不同的节点上，每个节点有4个核心、16G内存。你需要对于输入的每一个 x ，计算得出最终的 output 。

y1=ReLU(x A)
y2=ReLU(y1 B)
y3=ReLU(y2 C)
output=ReLU(y3 D)

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
import os
import numpy as np
import ray

def relu(x):
    return np.maximum(0, x)

@ray.remote
def compute(input, weight):
    return relu(np.dot(input, np.load(weight)))

ray.init(address=f"{os.environ['RAY_CLUSTER_ADDR']}")

tasks = []
for i in range(100):
    input = f"inputs/input_{i}.npy"
    task = compute.remote(np.load(input), "weights/weight_0.npy")
    for j in range(1, 4):
        task = compute.remote(task, f"weights/weight_{j}.npy")
    tasks.append(task)

outputs = ray.get(tasks)

os.makedirs("outputs", exist_ok=True)
for i, output in enumerate(outputs):
    np.save(f"outputs/output_{i}.npy", output)

根据题意，需要使用Ray来进行分布式计算

这道题测评易出问题，后续需要排队测评，本地调试配环境比较困难，因此到最后一天才做出来，而且写的非常粗糙。题干说明了输入输出文件有高速io，但是权重文件没有，因此AC答案应该是 O(weight+100input) ，而我的答案是 O(100(weight+input))，因此只拿到了部分分数，解答仅作为参考。

补充了ray的相关知识，是一道很有新意的题，题目本身不算困难。关于Ray核心介绍。

F. 高性能数据校验

本题使用一种基于 SHA512 算法的可并行数据校验算法对数据进行分块校验。（SHA512 是一种高度安全的校验码实现，具体算法不需关心）

算法的流程如下（对算法的具体解释见 baseline 代码）：

  1. 对数据进行分块，每一块的大小为 M=1MB，记划分的块数为 n。如果文件剩余内容不足一块的大小，则补二进制0至一个块大小。
  2. 对于第 i 个块，在其末尾连接上第 i-1 个块的 SHA512 校验码的二进制值，将所得到的 M + 64 大小的数据进行 SHA512 校验，得到第 i 个块的校验码。（i 从 0 开始） 注，第 -1 个块的校验码为空文件的校验码
  3. 最后一个块的校验码，即为文件的校验码 注，大小为0的文件的校验码定义为空文件的 SHA512 校验码
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
#include <algorithm>
#include <chrono>
#include <cstring>
#include <filesystem>
#include <fstream>
#include <iostream>
#include <mpi.h>
#include <openssl/evp.h>
#include <openssl/sha.h>
#include <sys/types.h>
#include <sys/stat.h>
#include <fcntl.h>
#include <sys/mman.h>
#include <unistd.h>

namespace fs = std::filesystem;

constexpr size_t BLOCK_SIZE = 1024 * 1024;

EVP_MD_CTX* ctx[16384];


int main(int argc, char *argv[]) {

    MPI_Init(&argc, &argv);

    int rank, nprocs;
    MPI_Comm_rank(MPI_COMM_WORLD, &rank);
    MPI_Comm_size(MPI_COMM_WORLD, &nprocs);

    fs::path input_path = argv[1];
    fs::path output_path = argv[2];

    auto file_size = fs::file_size(input_path);

    int num_block = (file_size + BLOCK_SIZE - 1) / BLOCK_SIZE;
    int blocks_per_proc = (num_block + nprocs - 1) / nprocs;

    //MPI_File file;
auto start = std::chrono::high_resolution_clock::now();

    //MPI_File_open(MPI_COMM_WORLD, input_path.c_str(), MPI_MODE_RDONLY, MPI_INFO_NULL, &file);

    int fd = open(input_path.c_str(), O_RDONLY);
if (fd == -1) {
    perror("Error opening file for reading");
    MPI_Abort(MPI_COMM_WORLD, EXIT_FAILURE);
}

struct stat sb;
if (fstat(fd, &sb) == -1) {
    perror("fstat");
    MPI_Abort(MPI_COMM_WORLD, EXIT_FAILURE);
}

// Each process maps its part of the file
uint64_t offset = rank * blocks_per_proc * BLOCK_SIZE;
long int sizes = blocks_per_proc * BLOCK_SIZE;


uint8_t *buffer = static_cast<uint8_t*>(mmap(0, sizes, PROT_READ, MAP_SHARED, fd, offset));
if (buffer == MAP_FAILED) {
    close(fd);
    perror("Error mmapping the file");
    MPI_Abort(MPI_COMM_WORLD, EXIT_FAILURE);
}


    //uint8_t *buffer = new uint8_t[blocks_per_proc * BLOCK_SIZE];

// Each process reads its part of the file
//uint64_t offset = rank * blocks_per_proc * BLOCK_SIZE;
//long int sizes = blocks_per_proc * BLOCK_SIZE;
//if (sizes == 2147483648){
//    sizes = sizes/2;
//}
//
//offset
//MPI_File_read_at(file, offset, buffer, sizes, MPI_BYTE, MPI_STATUS_IGNORE);

//if (sizes == blocks_per_proc * BLOCK_SIZE/2){
//    MPI_File_read_at(file, offset+sizes, buffer+sizes, sizes, MPI_BYTE, MPI_STATUS_IGNORE);
//}
//    MPI_File_close(&file);

    for (int i = 0; i < blocks_per_proc; i++) {
    ctx[i] = EVP_MD_CTX_new();
    }
    EVP_MD *sha512 = EVP_MD_fetch(nullptr, "SHA512", nullptr);

    for (int i = 0; i < blocks_per_proc; i++) {
    EVP_DigestInit_ex(ctx[i], sha512, nullptr);
    EVP_DigestUpdate(ctx[i], buffer + i * BLOCK_SIZE, BLOCK_SIZE);
    }
auto end = std::chrono::high_resolution_clock::now();
auto duration = std::chrono::duration_cast<std::chrono::milliseconds>(end - start);
std::cout << "File reading took " << duration.count() << " milliseconds\n";

    //delete[] buffer;
  if (rank == 0) {
    // calculate the checksum
    uint8_t obuf[SHA512_DIGEST_LENGTH];
      uint8_t prev_md[SHA512_DIGEST_LENGTH] = {
      0xcf, 0x83, 0xe1, 0x35, 0x7e, 0xef, 0xb8, 0xbd, 0xf1, 0x54, 0x28, 0x50,
      0xd6, 0x6d, 0x80, 0x07, 0xd6, 0x20, 0xe4, 0x05, 0x0b, 0x57, 0x15, 0xdc,
      0x83, 0xf4, 0xa9, 0x21, 0xd3, 0x6c, 0xe9, 0xce, 0x47, 0xd0, 0xd1, 0x3c,
      0x5d, 0x85, 0xf2, 0xb0, 0xff, 0x83, 0x18, 0xd2, 0x87, 0x7e, 0xec, 0x2f,
      0x63, 0xb9, 0x31, 0xbd, 0x47, 0x41, 0x7a, 0x81, 0xa5, 0x38, 0x32, 0x7a,
      0xf9, 0x27, 0xda, 0x3e};

// 3 串行
  for (int i = 0; i < blocks_per_proc; i++) {
    unsigned int len_out = 0;
    EVP_DigestUpdate(ctx[i], prev_md, SHA512_DIGEST_LENGTH);
    EVP_DigestFinal_ex(ctx[i], prev_md, &len_out);
    ////EVP_MD_CTX_free(ctx[i]);
  }
 //将prev_md发送给rank1
    MPI_Send(prev_md, SHA512_DIGEST_LENGTH, MPI_BYTE, 1, 0, MPI_COMM_WORLD);
    }
    if (rank == 1) {
        //接收rank0的结果当做prev_md
        uint8_t prev_md[SHA512_DIGEST_LENGTH];
        MPI_Recv(prev_md, SHA512_DIGEST_LENGTH, MPI_BYTE, 0, 0, MPI_COMM_WORLD, MPI_STATUS_IGNORE);

        for (int i = 0; i < blocks_per_proc; i++) {
        unsigned int len_out = 0;
        EVP_DigestUpdate(ctx[i], prev_md, SHA512_DIGEST_LENGTH);
        EVP_DigestFinal_ex(ctx[i], prev_md, &len_out);
        //EVP_MD_CTX_free(ctx[i]);
        }
        //
        MPI_Send(prev_md, SHA512_DIGEST_LENGTH, MPI_BYTE, 2, 0, MPI_COMM_WORLD);
    }
    if (rank == 2) {
        uint8_t prev_md[SHA512_DIGEST_LENGTH];
        MPI_Recv(prev_md, SHA512_DIGEST_LENGTH, MPI_BYTE, 1, 0, MPI_COMM_WORLD, MPI_STATUS_IGNORE);

        for (int i = 0; i < blocks_per_proc; i++) {
        unsigned int len_out = 0;
        EVP_DigestUpdate(ctx[i], prev_md, SHA512_DIGEST_LENGTH);
        EVP_DigestFinal_ex(ctx[i], prev_md, &len_out);
        //EVP_MD_CTX_free(ctx[i]);
        }

        MPI_Send(prev_md, SHA512_DIGEST_LENGTH, MPI_BYTE, 3, 0, MPI_COMM_WORLD);
    }
    if (rank == 3) {
        uint8_t prev_md[SHA512_DIGEST_LENGTH];
        MPI_Recv(prev_md, SHA512_DIGEST_LENGTH, MPI_BYTE, 2, 0, MPI_COMM_WORLD, MPI_STATUS_IGNORE);

        for (int i = 0; i < blocks_per_proc; i++) {
        unsigned int len_out = 0;
        EVP_DigestUpdate(ctx[i], prev_md, SHA512_DIGEST_LENGTH);
        EVP_DigestFinal_ex(ctx[i], prev_md, &len_out);
        //EVP_MD_CTX_free(ctx[i]);
        }

        MPI_Send(prev_md, SHA512_DIGEST_LENGTH, MPI_BYTE, 4, 0, MPI_COMM_WORLD);
    }
    if (rank == 4) {
        uint8_t prev_md[SHA512_DIGEST_LENGTH];
        MPI_Recv(prev_md, SHA512_DIGEST_LENGTH, MPI_BYTE, 3, 0, MPI_COMM_WORLD, MPI_STATUS_IGNORE);

        for (int i = 0; i < blocks_per_proc; i++) {
        unsigned int len_out = 0;
        EVP_DigestUpdate(ctx[i], prev_md, SHA512_DIGEST_LENGTH);
        EVP_DigestFinal_ex(ctx[i], prev_md, &len_out);
        //EVP_MD_CTX_free(ctx[i]);
        }

        MPI_Send(prev_md, SHA512_DIGEST_LENGTH, MPI_BYTE, 5, 0, MPI_COMM_WORLD);
    }
    if (rank == 5) {
        uint8_t prev_md[SHA512_DIGEST_LENGTH];
        MPI_Recv(prev_md, SHA512_DIGEST_LENGTH, MPI_BYTE, 4, 0, MPI_COMM_WORLD, MPI_STATUS_IGNORE);

        for (int i = 0; i < blocks_per_proc; i++) {
        unsigned int len_out = 0;
        EVP_DigestUpdate(ctx[i], prev_md, SHA512_DIGEST_LENGTH);
        EVP_DigestFinal_ex(ctx[i], prev_md, &len_out);
        //EVP_MD_CTX_free(ctx[i]);
        }

        MPI_Send(prev_md, SHA512_DIGEST_LENGTH, MPI_BYTE, 6, 0, MPI_COMM_WORLD);
    }
    if (rank == 6) {
        uint8_t prev_md[SHA512_DIGEST_LENGTH];
        MPI_Recv(prev_md, SHA512_DIGEST_LENGTH, MPI_BYTE, 5, 0, MPI_COMM_WORLD, MPI_STATUS_IGNORE);

        for (int i = 0; i < blocks_per_proc; i++) {
        unsigned int len_out = 0;
        EVP_DigestUpdate(ctx[i], prev_md, SHA512_DIGEST_LENGTH);
        EVP_DigestFinal_ex(ctx[i], prev_md, &len_out);
        //EVP_MD_CTX_free(ctx[i]);
        }

        MPI_Send(prev_md, SHA512_DIGEST_LENGTH, MPI_BYTE, 7, 0, MPI_COMM_WORLD);
    }
    if (rank == 7) {
        uint8_t prev_md[SHA512_DIGEST_LENGTH];
        MPI_Recv(prev_md, SHA512_DIGEST_LENGTH, MPI_BYTE, 6, 0, MPI_COMM_WORLD, MPI_STATUS_IGNORE);

        for (int i = 0; i < blocks_per_proc; i++) {
        unsigned int len_out = 0;
        EVP_DigestUpdate(ctx[i], prev_md, SHA512_DIGEST_LENGTH);
        EVP_DigestFinal_ex(ctx[i], prev_md, &len_out);
        //EVP_MD_CTX_free(ctx[i]);
        }

            // write prev_md to output file
            std::ofstream ostrm(output_path, std::ios::binary);
for (int i = 0; i < SHA512_DIGEST_LENGTH; i++) {
    ostrm << std::hex << std::setw(2) << std::setfill('0') << static_cast<int>(prev_md[i]);
}
ostrm.close();
    }




  MPI_Finalize();
  return 0;
}

根据题意构造如下MPI流程：

  1. 同步加载文件，每个进程加载自己需要计算的部分
  2. 每个进程计算自己的部分的SHA512，将结果发给下一个进程

因为该题目要求计算的值是递归依赖的，所以不能单纯并行来计算。在我的算法中，实际上计算仍是串行的，另外采取了mmap的方式来加载文件（如果算法更好应该是不需要mmap也能AC）。

G. 3D生命游戏

在本题中，你将研究拓展到三维版本的康威生命游戏。在三维版本中，每个细胞有26个邻居，状态转移规则如下：

  • 当细胞为存活状态时
    如果周围存活的细胞低于5个（不包含5个）时，细胞变为死亡状态
    如果周围存活的细胞有5到7个时（包含5和7），则细胞保持存活
    如果周围存活的细胞超过7个（不包括7个）时，细胞变为死亡状态
  • 当细胞为死亡状态时
    如果周围有6个存活细胞时，该细胞变成存活状态

同时我们希望研究无限空间大小下的生命游戏。但是，无限空间难以在计算机中表示，因此，我们采取一种”循环“的策略，来模拟无限空间。具体规则为：若有效信息的块的边长为 M ，则无限空间中任意一点 (x,y,z) 对应有效信息块中的位置为 (xmodM,ymodM,zmodM) 。

提交单个cuda源代码文件，评测系统将会用nvcc -O3来编译你的程序。

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
//cuda
#include <cstddef>
#include <cstdint>
#include <filesystem>
#include <fstream>
#include <iostream>
#include <utility>
#include <cuda.h>
#include <sys/mman.h>
#include <sys/stat.h>
#include <fcntl.h>
#include <unistd.h>
namespace fs = std::filesystem;

__global__ void update_all_states(uint8_t *curr_space, uint8_t *next_space, int M) {
  int x = blockIdx.x;
  int y = blockIdx.y;
  int z = threadIdx.x;

  size_t lx = ((x + M - 1) % M) * M * M;
  size_t mx = x * M * M;
  size_t rx = ((x + 1) % M) * M * M;

  size_t ly = ((y + M - 1) % M) * M;
  size_t my = y * M;
  size_t ry = ((y + 1) % M) * M;

  size_t lz = (z + M - 1) % M;
  size_t mz = z;
  size_t rz = (z + 1) % M;

  int neighbor_count = curr_space[lx + ly + lz] + curr_space[lx + ly + mz] +
                       curr_space[lx + ly + rz] + curr_space[lx + my + lz] +
                       curr_space[lx + my + mz] + curr_space[lx + my + rz] +
                       curr_space[lx + ry + lz] + curr_space[lx + ry + mz] +
                       curr_space[lx + ry + rz] + curr_space[mx + ly + lz] +
                       curr_space[mx + ly + mz] + curr_space[mx + ly + rz] +
                       curr_space[mx + my + lz] + curr_space[mx + my + rz] +
                       curr_space[mx + ry + lz] + curr_space[mx + ry + mz] +
                       curr_space[mx + ry + rz] + curr_space[rx + ly + lz] +
                       curr_space[rx + ly + mz] + curr_space[rx + ly + rz] +
                       curr_space[rx + my + lz] + curr_space[rx + my + mz] +
                       curr_space[rx + my + rz] + curr_space[rx + ry + lz] +
                       curr_space[rx + ry + mz] + curr_space[rx + ry + rz];

  uint8_t curr_state = curr_space[mx + my + mz];
  uint8_t &next_state = next_space[mx + my + mz];

  next_state = (curr_state == 1) ? (neighbor_count >= 5 && neighbor_count <= 7) : (neighbor_count == 6);
}



int main(int argc, char *argv[]) {
  if (argc < 4) {
    std::cout << "Usage: " << argv[0] << " <input_path> <output_path> <N>"
              << std::endl;
    return 1;
  }

  fs::path input_path = argv[1];
  fs::path output_path = argv[2];
  int N = std::atoi(argv[3]);

  int fd = open(input_path.c_str(), O_RDONLY);
  if (fd == -1) {
    std::cerr << "Error opening file" << std::endl;
    return 1;
  }

  struct stat sb;
  if (fstat(fd, &sb) == -1) {
    std::cerr << "Error getting file size" << std::endl;
    return 1;
  }

  char *file_in_memory = static_cast<char *>(mmap(NULL, sb.st_size, PROT_READ, MAP_PRIVATE, fd, 0));
  if (file_in_memory == MAP_FAILED) {
    std::cerr << "Error mapping file" << std::endl;
    return 1;
  }

  size_t M = *reinterpret_cast<size_t *>(file_in_memory);
  size_t T = *reinterpret_cast<size_t *>(file_in_memory + sizeof(size_t));

  uint8_t *curr_space;
  uint8_t *next_space;
  cudaMallocManaged(&curr_space, M * M * M * sizeof(uint8_t));
  cudaMallocManaged(&next_space, M * M * M * sizeof(uint8_t));

  std::copy(file_in_memory + 2 * sizeof(size_t), file_in_memory + sb.st_size, curr_space);

  dim3 blocks(M, M);
  dim3 threads(M);

  for (int t = 0; t < N; t++) {
    update_all_states<<<blocks, threads>>>(curr_space, next_space, M);
    cudaDeviceSynchronize();
    std::swap(curr_space, next_space);
  }

  T += N;


  std::ofstream output_file(output_path, std::ios::binary);
  output_file.write(reinterpret_cast<char *>(&M), sizeof(M));
  output_file.write(reinterpret_cast<char *>(&T), sizeof(T));
  output_file.write(reinterpret_cast<char *>(curr_space), M * M * M);

  cudaFree(curr_space);
  cudaFree(next_space);
  munmap(file_in_memory, sb.st_size);
  close(fd);
  return 0;
}

该题根据题意是编写3D生命游戏的cuda代码。根据baseline文件将其改写为cuda版本如上。因为没有优化，因此只有极少的分数。

我做此题时尝试不少优化方法，但没有成功。一个非常明显的优化方式是将读取的数据加载进共享内存，可以避免全局内存的频繁存取降低性能。由于时间原因，没有来得及实现。

H. 矩阵乘法

你需要从文件 conf.data 中读取两个矩阵 M1 ，M2 并计算乘积 M3 =M1 ⋅ M2 ，然后将结果写入文件 out.data 中。

输入文件为一个二进制文件，定义如下：

  1. 三个 64 位整数 N1 , N2 , N3 ；
  2. 第一个矩阵 M1 的数据，矩阵有 N1 行、N2 列，以 64 位浮点的形式存储，顺序为行优先；
  3. 第一个矩阵 M2 的数据，矩阵有 N2 行、N3 列，以 64 位浮点的形式存储，顺序为行优先。

将矩阵 M3 直接写入输出文件中，以 64 位浮点的形式存储，顺序为行优先。

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87

#include <iostream>
//#include <chrono>
#include <immintrin.h>
#include <omp.h>
#include <sys/mman.h>
#include <sys/stat.h>
#include <fcntl.h>
#include <unistd.h>
#define BLOCK_SIZE 64


void mul(double* a, double* b, double* c, uint64_t n1, uint64_t n2, uint64_t n3) {
 #pragma omp parallel for
 for (uint64_t ii = 0; ii < n1; ii += BLOCK_SIZE) {
  for (uint64_t jj = 0; jj < n2; jj += BLOCK_SIZE) {
   for (uint64_t kk = 0; kk < n3; kk += BLOCK_SIZE) {
    for (uint64_t i = ii; i < std::min(ii + BLOCK_SIZE, n1); i++) {
     for (uint64_t j = jj; j < std::min(jj + BLOCK_SIZE, n2); j++) {
      __m512d a_val = _mm512_set1_pd(a[i * n2 + j]);
      for (uint64_t k = kk; k < std::min(kk + BLOCK_SIZE, n3); k += 8) {
       __m512d b_val = _mm512_loadu_pd(&b[j * n3 + k]);
       __m512d c_val = _mm512_loadu_pd(&c[i * n3 + k]);
       c_val = _mm512_fmadd_pd(a_val, b_val, c_val);
       _mm512_storeu_pd(&c[i * n3 + k], c_val);
      }
     }
    }
   }
  }
 }
}

int main() {
    uint64_t n1, n2, n3;
    int fd;

    fd = open("conf.data", O_RDONLY);
    struct stat sb;
    fstat(fd, &sb);
    void* mapped = mmap(0, sb.st_size, PROT_READ, MAP_PRIVATE, fd, 0);

    uint64_t* p = (uint64_t*)mapped;
    n1 = *p++;
    n2 = *p++;
    n3 = *p++;

    double* a = (double*)p; p += n1 * n2;
    double* b = (double*)p; p += n2 * n3;

    double* c = (double*)aligned_alloc(64, n1 * n3 * 8);

    for (uint64_t i = 0; i < n1; i++) {
        for (uint64_t k = 0; k < n3; k++) {
            c[i * n3 + k] = 0;
        }
    }

    //auto t1 = std::chrono::steady_clock::now();
    mul(a, b, c, n1, n2, n3);
    //auto t2 = std::chrono::steady_clock::now();
    //int d1 = std::chrono::duration_cast<std::chrono::milliseconds>(t2 - t1).count();
    //printf("%d\n", d1);

    FILE* fi = fopen("out.data", "wb");
    fwrite(c, 1, n1 * n3 * 8, fi);

    fclose(fi);

        //输出c
    //printf("c:\n");
    //for (uint64_t i = 0; i < 5; i++) {
    //    for (uint64_t k = 0; k < 5; k++) {
    //        printf("%lf ", c[i * 5 + k]);
    //    }
    //    printf("\n");
    //}


    munmap(mapped, sb.st_size);
    close(fd);

    free(c);

    return 0;
}

该题目是非常经典的矩阵乘法计算。编译选项为 -O3 -fopenmp -mavx512f，因此根据题意使用GEMM算法，使用openmp/mavx512f进行优化。后续又尝试分块计算，或者循环展开，手写GEMM，提升效果均不明显。这道题也是我头疼时间比较长的，只拿到了部分分数。感觉没有GET到优化的点，后续有时间再研究。

I.LOGISTIC方程

计算 n 个 64 位浮点数的 itn 次 logistic 映射，所有浮点数会使用相同参数 r。n 为 1024 的整数倍。

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
#include <iostream>
#include <chrono>
#include <immintrin.h>
#include <omp.h>
#include <fstream>
void itv(double r, double* x, int64_t n, int64_t itn) {
    #pragma omp parallel for num_threads(8)
    for (int64_t i = 0; i < n; i += 64) {
        __m512d xv1 = _mm512_load_pd(&x[i]);
        __m512d xv2 = _mm512_load_pd(&x[i+8]);
        __m512d xv3 = _mm512_load_pd(&x[i+16]);
        __m512d xv4 = _mm512_load_pd(&x[i+24]);
        __m512d xv5 = _mm512_load_pd(&x[i+32]);
        __m512d xv6 = _mm512_load_pd(&x[i+40]);
        __m512d xv7 = _mm512_load_pd(&x[i+48]);
        __m512d xv8 = _mm512_load_pd(&x[i+56]);
        __m512d rv = _mm512_set1_pd(r);
        for (int64_t j = 0; j < itn; j++) {
            xv1 = _mm512_mul_pd(_mm512_mul_pd(rv, xv1), _mm512_sub_pd(_mm512_set1_pd(1.0), xv1));
            xv2 = _mm512_mul_pd(_mm512_mul_pd(rv, xv2), _mm512_sub_pd(_mm512_set1_pd(1.0), xv2));
            xv3 = _mm512_mul_pd(_mm512_mul_pd(rv, xv3), _mm512_sub_pd(_mm512_set1_pd(1.0), xv3));
            xv4 = _mm512_mul_pd(_mm512_mul_pd(rv, xv4), _mm512_sub_pd(_mm512_set1_pd(1.0), xv4));
            xv5 = _mm512_mul_pd(_mm512_mul_pd(rv, xv5), _mm512_sub_pd(_mm512_set1_pd(1.0), xv5));
            xv6 = _mm512_mul_pd(_mm512_mul_pd(rv, xv6), _mm512_sub_pd(_mm512_set1_pd(1.0), xv6));
            xv7 = _mm512_mul_pd(_mm512_mul_pd(rv, xv7), _mm512_sub_pd(_mm512_set1_pd(1.0), xv7));
            xv8 = _mm512_mul_pd(_mm512_mul_pd(rv, xv8), _mm512_sub_pd(_mm512_set1_pd(1.0), xv8));
        }
        _mm512_store_pd(&x[i], xv1);
        _mm512_store_pd(&x[i+8], xv2);
        _mm512_store_pd(&x[i+16], xv3);
        _mm512_store_pd(&x[i+24], xv4);
        _mm512_store_pd(&x[i+32], xv5);
        _mm512_store_pd(&x[i+40], xv6);
        _mm512_store_pd(&x[i+48], xv7);
        _mm512_store_pd(&x[i+56], xv8);
    }
}

int main()
{
    std::ifstream fi("conf.data", std::ios::binary);

    int64_t itn;
    double r;
    int64_t n;
    double *x;

    fi.read(reinterpret_cast<char *>(&itn), sizeof(itn));
    fi.read(reinterpret_cast<char *>(&r), sizeof(r));
    fi.read(reinterpret_cast<char *>(&n), sizeof(n));
    x = (double *)_mm_malloc(n * sizeof(double), 64);
    fi.read(reinterpret_cast<char *>(x), n * sizeof(double));

    itv(r, x, n, itn);

    std::ofstream fo("out.data", std::ios::binary);
    fo.write(reinterpret_cast<const char *>(x), n * sizeof(double));

    _mm_free(x);

    return 0;
}

该题使用基本的openmp/mavx512f进行优化后能拿到73分，只有用循环展开进行优化才能拿到满分，这道题也是比较需要GET到优化的点才能拿满的。

我一开始以为是要根据Logistic映射的特性，分收敛和周期范围的情况进行计算，能够收敛时检测是否收敛（差小于0.0000005，按题意取到这个精度）得到收敛的位置；能够进入周期时候检测进入周期的点（或者检测第一次出现最后结果的点，从那个点直接跳到结尾），这样最优情况下能将itn次计算减少到几十次，能够在几十ms内完成计算，有效验证了收敛和周期的情况（大嘘）。结果交上去发现测评值全是发散的（即上述判断的最坏情况，退化回itn次计算），一度怀疑自己，后来才想到循环展开。

写都写了，不能浪费，分收敛和周期范围的情况计算Logistic值的代码如下

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
//如果您要引用这段代码，请标明出处
#include <iostream>
#include <chrono>
#include <immintrin.h>
#include <omp.h>
#include <fstream>
#include <chrono>
#include <vector>
#include <unordered_map>
#include <vector>
#include <unordered_map>

int detect_period(const std::unordered_map<int64_t, double> &history_map)
{
    std::unordered_map<int64_t, int64_t> distances;
    int64_t max_count = 0;
    int64_t period = 0;

    std::vector<std::pair<int64_t, double>> history(history_map.begin(), history_map.end());

#pragma omp parallel for
    for (int64_t i = 0; i < history.size(); ++i)
    {
        std::unordered_map<int64_t, int64_t> local_distances;
        int64_t local_max_count = 0;
        int64_t local_period = 0;
        for (int64_t j = i + 1; j < history.size(); ++j)
        {
            if (history[i].second == history[j].second)
            {
                int64_t distance = history[j].first - history[i].first;
                local_distances[distance]++;
                if (local_distances[distance] > local_max_count)
                {
                    local_max_count = local_distances[distance];
                    local_period = distance;
                }
                break;
            }
        }
#pragma omp critical
        {
            if (local_max_count > max_count)
            {
                max_count = local_max_count;
                period = local_period;
            }
        }
    }
    return period;
}
void process_with_period(double vr, double one, double *x, int64_t n, int64_t itn)
{
    __m512d v_vr = _mm512_set1_pd(vr);
    __m512d v_one = _mm512_set1_pd(one);

    std::unordered_map<int64_t, double> history;
    double vxt = x[0];
    int64_t period = 0;
    int64_t start = 0;

    for (int64_t j = 0; j < itn; j++)
    {
        double next_vx = vr * vxt * (one - vxt);
        history[j] = vxt;
        vxt = next_vx;
    }
    period = detect_period(history);
    if (period != 0)
    {
        double lastnum = history[itn - 1];
        for (int64_t j = 0; j < itn; j++)
        {
            if (history[j] == lastnum)
            {
                start = j;
                break;
            }
        }
    }
    // Detect the period

    printf("period: %d\n", period);
    printf("start: %d\n", start);

    if (period == 0)
    {
#pragma omp parallel num_threads(8)
#pragma omp for
        for (int64_t i = 0; i < n; i += 8)
        {
            __m512d vx = _mm512_load_pd(x + i);
            for (int64_t js = 0; js < itn; js++)
            {
                vx = _mm512_mul_pd(_mm512_mul_pd(v_vr, vx), _mm512_sub_pd(v_one, vx));
            }
            _mm512_store_pd(x + i, vx);
        }
    }
    else
    {
#pragma omp parallel num_threads(8)
#pragma omp for
        for (int64_t i = 0; i < n; i += 8)
        {
            __m512d vx = _mm512_load_pd(x + i);
            for (int64_t js = 0; js < itn; js++)
            {
                if (period != 0 && js >= start && start + period < itn)
                {
                    js += (itn / period) * period;
                }
                vx = _mm512_mul_pd(_mm512_mul_pd(v_vr, vx), _mm512_sub_pd(v_one, vx));
            }
            _mm512_store_pd(x + i, vx);
        }
    }
}

void process(__m512d vr, __m512d one, double *x, int64_t n, int64_t itn)
{
#pragma omp parallel for num_threads(8)
    for (int64_t i = 0; i < n; i += 8)
    {
        __m512d vx = _mm512_load_pd(x + i);
        __m512d prev_vx = vx;
        for (int64_t j = 0; j < itn; j++)
        {
            vx = _mm512_mul_pd(_mm512_mul_pd(vr, vx), _mm512_sub_pd(one, vx));
            __m512d diff = _mm512_sub_pd(vx, prev_vx);
            __m512d abs_diff = _mm512_abs_pd(diff);
            if (_mm512_reduce_max_pd(abs_diff) < 0.0000005)
                break;
            prev_vx = vx;
        }
        _mm512_store_pd(x + i, vx);
    }
}

int main()
{
    std::ifstream fi("conf.data", std::ios::binary);

    int64_t itn;
    double r;
    int64_t n;
    double *x;

    fi.read(reinterpret_cast<char *>(&itn), sizeof(itn));
    fi.read(reinterpret_cast<char *>(&r), sizeof(r));
    fi.read(reinterpret_cast<char *>(&n), sizeof(n));
    x = (double *)_mm_malloc(n * sizeof(double), 64);
    fi.read(reinterpret_cast<char *>(x), n * sizeof(double));

    // itv function content starts here
    // 如果r大于1.3小于2.6，则将itn设为20
    if (r < 3)
    {
        __m512d vr = _mm512_set1_pd(r);
        __m512d one = _mm512_set1_pd(1.0);
        process(vr, one, x, n, itn);
    }
    else
    {
        process_with_period(r, 1.0, x, n, itn);
    }
    // itv function content ends here

    std::ofstream fo("out.data", std::ios::binary);
    // 输出结果
    printf("%lf\n", x[0]);

    fo.write(reinterpret_cast<const char *>(x), n * sizeof(double));

    _mm_free(x);

    return 0;
}

J. H-66

官方题解

K. 光之游戏

官方题解

L. 洪水困兽

我们提供了一个 Handout，提供了串行版本代码和测试数据。你需要在 Handout 的基础上，使用 OpenMP 实现并行化的 particle2grid 过程。以下是对这一过程算法的详细介绍。

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
#include <array>
#include <fstream>
#include <iostream>
#include <omp.h>
#include <vector>
#include <cmath>
#include <tuple>

using std::vector, std::array, std::tuple, std::string;

void particle2grid(int resolution, int numparticle,
                   const vector<double> &particle_position,
                   const vector<double> &particle_velocity,
                   vector<double> &velocityu, vector<double> &velocityv,
                   vector<double> &weightu, vector<double> &weightv) {
    double grid_spacing = 1.0 / resolution;
    double inv_grid_spacing = 1.0 / grid_spacing;
    auto get_frac = [&inv_grid_spacing](double x, double y) {
        int xidx = floor(x * inv_grid_spacing);
        int yidx = floor(y * inv_grid_spacing);
        double fracx = x * inv_grid_spacing - xidx;
        double fracy = y * inv_grid_spacing - yidx;
        return tuple(array<int, 2>{xidx, yidx},
                     array<double, 4>{fracx * fracy, (1 - fracx) * fracy,
                                      fracx * (1 - fracy),
                                      (1 - fracx) * (1 - fracy)});
    };
    #pragma omp parallel for
    for (int i = 0; i < numparticle; i++) {
        array<int, 4> offsetx = {0, 1, 0, 1};
        array<int, 4> offsety = {0, 0, 1, 1};

        auto [idxu, fracu] =
            get_frac(particle_position[i * 2 + 0],
                     particle_position[i * 2 + 1] - 0.5 * grid_spacing);
        auto [idxv, fracv] =
            get_frac(particle_position[i * 2 + 0] - 0.5 * grid_spacing,
                     particle_position[i * 2 + 1]);

        for (int j = 0; j < 4; j++) {
            int tmpidx = 0;
            tmpidx =
                (idxu[0] + offsetx[j]) * resolution + (idxu[1] + offsety[j]);
            #pragma omp atomic
            velocityu[tmpidx] += particle_velocity[i * 2 + 0] * fracu[j];
            #pragma omp atomic
            weightu[tmpidx] += fracu[j];

            tmpidx = (idxv[0] + offsetx[j]) * (resolution + 1) +
                     (idxv[1] + offsety[j]);

            #pragma omp atomic
            velocityv[tmpidx] += particle_velocity[i * 2 + 1] * fracv[j];
            #pragma omp atomic
            weightv[tmpidx] += fracv[j];
        }
    }
}
int main(int argc, char *argv[]) {
    if (argc < 2) {
        printf("Usage: %s inputfile\n", argv[0]);
        return -1;
    }

    string inputfile(argv[1]);
    std::ifstream fin(inputfile, std::ios::binary);
    if (!fin) {
        printf("Error opening file");
        return -1;
    }

    int resolution;
    int numparticle;
    vector<double> particle_position;
    vector<double> particle_velocity;

    fin.read((char *)(&resolution), sizeof(int));
    fin.read((char *)(&numparticle), sizeof(int));

    particle_position.resize(numparticle * 2);
    particle_velocity.resize(numparticle * 2);

    printf("resolution: %d\n", resolution);
    printf("numparticle: %d\n", numparticle);

    fin.read((char *)(particle_position.data()),
             sizeof(double) * particle_position.size());
    fin.read((char *)(particle_velocity.data()),
             sizeof(double) * particle_velocity.size());

    vector<double> velocityu((resolution + 1) * resolution, 0.0);
    vector<double> velocityv((resolution + 1) * resolution, 0.0);
    vector<double> weightu((resolution + 1) * resolution, 0.0);
    vector<double> weightv((resolution + 1) * resolution, 0.0);


    string outputfile;

    particle2grid(resolution, numparticle, particle_position,
                    particle_velocity, velocityu, velocityv, weightu,
                    weightv);
    outputfile = "output.dat";

    std::ofstream fout(outputfile, std::ios::binary);
    if (!fout) {
        printf("Error output file");
        return -1;
    }
    fout.write((char *)(&resolution), sizeof(int));
    fout.write(reinterpret_cast<char *>(velocityu.data()),
               sizeof(double) * velocityu.size());
    fout.write(reinterpret_cast<char *>(velocityv.data()),
               sizeof(double) * velocityv.size());
    fout.write(reinterpret_cast<char *>(weightu.data()),
               sizeof(double) * weightu.size());
    fout.write(reinterpret_cast<char *>(weightv.data()),
               sizeof(double) * weightv.size());

    return 0;
}

按照一般思路进行并行优化即可。


M. RISC-V OPENBLAS

官方题解

N. RISC-V LLM

官方题解

总结

整体体验下来非常好，题目很有意思，分配的计算资源也很充足。虽然服务器不太稳定，但组委会的成员解决问题都很及时，总体来说是一场很棒的比赛。参加这次比赛收获良多，自身也有很多不足的地方，总之还是要多多学习，明年再来。 /heart

2024 PKU HPCGame WP

https://petalzu.top/2024/01/30/hpcgame2024/

作者

Petalzu

发布于

2024-01-30

更新于

2024-01-30

许可协议

#

评论

最新文章

分类

标签

AI1
ARG1
CTF4
FPGA1
GitHub Pages2
HPC3
HPCgame2
Hackergame2
NepCTF2
Neuro-Sama1
Petal2
Raspberry Pi1
Touhou Project3
ceph1
cloudflare2
cmake1
cuda1
docker1
hadoop1
hello world1
hexo1
hexo-theme-redefine1
makefile1
mpi1
openblas1
openmp1
openstack1
spark1
ssl1
书评3
云计算1
大数据1
嵌入式2
幻想战闻录1
开发板2
感觉与灵魂1
硬件2
超算3
边缘证书1
×
